RHD ECE SUV
  • RHD ECE SUV RHD ECE SUV

RHD ECE SUV

SUVs come in a variety of sizes, from compact models to full-size, luxury models. They are characterized by their spacious interiors, high seating position, and ample cargo space. Many SUVs also feature towing capabilities, making them useful for hauling trailers, boats, and other recreational vehicles. SUVs are known for their durability and ruggedness, as well as their advanced safety features. They can also be equipped with modern amenities such as advanced entertainment, navigation, and driver assistance systems. Our company provides high-quality RHD ECE SUV for the majority of users

Send Inquiry

Product Description

BE11-R01 RHD specification
Category Version 410
RHD 410 entry 		520
RHD 520EU confort 		620
RHD 620EU confort
[km]
NEDC working condition cruising range[km] 		400（NEDC） ● - -
400（WLTP） - ● -
489（WLTP） - - ●

Basic Information 		Certification Scope ECE ECE ECE
SOP 2024.5 2024.2 2024.2
Model level Medium SUV Medium SUV Medium SUV
Power Type Pure electric Pure electric Pure electric
Body Structure 16 Globe cage thermoforming reinforced structure 16 Globe cage thermoforming reinforced structure 16 Globe cage thermoforming reinforced structure
Gearbox Type Single-stage reducer Single-stage reducer Single-stage reducer
Vehicle thermal management Intelligent battery temperature control system Intelligent battery temperature control system Intelligent battery temperature control system
Energy recovery system Energy recovery is greater than 30% Energy recovery is greater than 30% Energy recovery is greater than 30%
Charger power [kW] 6.6 11 11
Battery fast charge time[h] ≤33min  20%-70%@20℃ ≤36min  20%-70%@20℃ ≤45min  20%-70%@20℃
Battery slow charging time [h] ≤5h10min 20%-70%@25℃ ≤4h30min(three-phase)20%-70%@25℃ ≤5h30min(three-phase)20%-70%@25℃
0-100km/h acceleration time [s] 9.6 9.6 9.6
Maximum speed [km/h] 150 150 150
Maximum grade ＞30% ＞30% ＞30%


Vehicle size 		××[mm]
Length x Width x Height (mm) 		4720x1908x1696 4720x1908x1696 4720x1908x1696
[mm]
Wheelbase (mm) 		2800 2800 2800
[]
No. of Seats 		5 5 5
[kg]
Curb Weight (kg) 		1820 1880 1930
[L]
Cargo Space[L] 		467—1141 467—1141 467—1141

Front tire specifications 		235/55 R18 235/50 R19 235/50 R19

Rear tire specifications 		235/55 R18 235/50 R19 235/50 R19
[mm]
Minimum Ground Clearance (mm) 		159 159 159


Dynamic parameters 		Gearbox type Single-stage reducer Single-stage reducer Single-stage reducer
Type of Drive Three-in-one efficient integration Three-in-one efficient integration Three-in-one efficient integration
Maximum Power Output [kw] 150 150 150
[kWh]
Electricity [kwh] 		51.92 71.984 85.966
Battery type LFP Ternary lithium battery Ternary lithium battery
Rated power [kw] 65 65 65
Rated torque [N.m] 135 135 135
Maximum Torque [N.m] 320 320 320


Chassis system 		Drive way Front Predecessor Front Predecessor Front Predecessor
Front suspension type MacPherson independent suspension MacPherson independent suspension MacPherson independent suspension
Rear suspension type Multi-link independent suspension Multi-link independent suspension Multi-link independent suspension
Front wheel brake type Ventilation plate Ventilation plate Ventilation plate
Rear wheel brake type Disc Disc Disc
Brake boost IBS IBS IBS
Parking brake type EPBi EPBi EPBi
steering system EPS EPS EPS
Body structure
Load-bearing 		Load-bearing Load-bearing
Aluminum alloy wheels Single color Dual color Dual color
Emergency tire repair fluid ● ● ●


Security configuration 		ABS ● ● ●
EBD/CBC ● ● ●
BA/EBA ● ● ●
ARS/TCS ● ● ●
ESC/DSC ● ● ●
DAB ● ● ●
PAB ● ● ●
SAB - ● ●
CAB - ● ●
Tire pressure monitoring ● ● ●
Rear child seat interface ● ● ●
Front seat belt force limiting belt pretension ● ● ●
Front seat belt height adjustable ● ● ●
No seat belt reminder Whole car Whole car Whole car
eCall ○ ○ ○


Driving assistance 		Cruise control - ● ●
Automatic Parking (APA) - ● ●
HAC ● ● ●
AUTO HOLD ● ● ●
HDC ● ● ●
Front parking radar - ● ●
Rear parking radar ● ● ●
360° Panoramic view - ● ●
HD Reverse image with dynamic guidance - ● ●
HD Reverse image ● - -
Low speed prompt tone outside the vehicle ● ● ●
Overspeed warning ● ● ●
Fatigue driving warning - ● ●


External configuration 		Headlight LED ● ● ●
LED daytime running lights ● ● ●
Automatic headlights ● ● ●
Electric headlight height adjustment ● ● ●
Panoramic skylight - ○ ●
Front and rear power windows ● ● ●
Automatic anti-pinch for power windows ● ● ●
Four doors one key lift ● ● ●
Motorized adjustment of exterior mirrors ● ● ●
Automatic heating of exterior mirrors - ● ●
Automatic folding of exterior mirrors - ● ●
Anti-glare inside rearview mirror Manual Automatic Automatic
Front boneless wiper With induction With induction With induction
Rear wiper ● ● ●
Electric tailgate - With induction With induction
Body metal paint ● ● ●
Under the front cover ● ● ●
Silver decoration on the front and lower edge Silver Silver Silver
Roof rack - Spray paint Spray paint
Central lock Remote control
Remote control
Remote control

smart key 		- ●
Smart entry 		●
Smart entry
●
Keyless start 		●
Keyless start 		●
Keyless start
Battery preheating ● ● ●
BMS ● ● ●


Internal material 		Plastic-lined instrument panel ● ● ●
Sun visor makeup mirror ● ● ●
Leather steering wheel - ● ●
Multifunction steering wheel ● ● ●
Steering wheel four-way adjustment ● ● ●
Automatic front air conditioning ● ● ●
Front refrigeration air conditioning - - -
Air conditioning refrigerant ●（R1234yf）
○（R134a）
● European standard (R1234yf)
○National standard (R134a) 		●（R1234yf）
○（R134a）
● European standard (R1234yf)
○National standard (R134a) 		●（R1234yf）
○（R134a）
● European standard (R1234yf)
○National standard (R134a)
Rear air conditioner outlet ● ● ●
Roof LED reading light ●Front ⭕ Front/Rear（skylight） ●Front//Rear
Air outlet in the armrest box ● ● ●
Fully covered front cabin trim cover ● ● ●
Covering curtain - ● ●
LED storage space lighting ● ● ●
Multi layer sound-absorbing carpet ● ● ●


Seat Configuration 		Seat material PVC PVC PVC
Driver seat adjustment Manual Electric Electric
Co-driver seat adjustment Manual Electric Electric
Driver seat adjustment mode •Back adjustment •Back adjustment •Back adjustment
•High and low adjustment •High and low adjustment •High and low adjustment
•Front and rear adjustment •Front and rear adjustment •Front and rear adjustment
Co-driver seat adjustment mode •Back adjustment •Back adjustment •Back adjustment
•High and low adjustment •High and low adjustment •High and low adjustment
•Front and rear adjustment •Front and rear adjustment •Front and rear adjustment

Rear seat angle adjustment 		● ● ●
Front center armrest ● ● ●
Rear center armrest ● ● ●
Rear seat reclining mode 4/6 4/6 4/6
Folding of rear seats ● ● ●
Rear cup holder ● ● ●

Skylink system
 Central control color
LCD screen 		10.2 inch touch LCD screen 12.8 inch touch LCD screen 12.8 inch touch LCD screen
Instrument 12.3-inch LCD instrument 12.3-inch LCD instrument 12.3-inch LCD instrument
Driving computer ● ● ●
Blue tooth ● ● ●
DAB station - ● ●
USB quantity 2 3 3
Number of speakers 2 8 8


Charging system 		Car inside220V power source - ● ●
Car inside 12V power source ● ● ●
trunk 12V power source - ● ●
Portable  Charger - - ●
Fast-charging interface ● ● ●
Slow-charging interface ● ● ●


Interior color 		Black (material: PVC) ● ● ●
Sheep fat white jade interior (material: microfiber) - ○ ○

2021 MODEL Front face(Shield marker SKYWELL) LxWxH[mm]:
4698x1908x1696 		⭕ ⭕ ⭕
2022 model front face (Letter marker SKYWORTH) LxWxH[mm]:
4720x1908x1696 		● ● ●

Remarks:
-  represents not available;
•   represents standard configuration.
⭕   rsepresents Optional;
The product is constantly updated and upgraded, configuration will be slightly adjusted within the legal scope. The final product configuration is subject to the final delivery.

Remarks：
eCall SIM cards are defined as types based on overseas order countries；
Panoramic skylight：The EU RHD 520 customized version comes standard without a panoramic skylight and comes with front reading lights. If a panoramic skylight is selected, the reading lights will be changed to front and rear seats
