EQ Right-hand drive BEV Configuration | |||||
Version :V3.0 | EQ02 | EQ 04 | EQ 04 | REMARKS | |
Exporting Country | Southeast Asia | Southeast Asia | Southeast Asia | ||
![]() |
![]() |
||||
Configuration: | 300km | 300km | 400km | ||
■Dimension | |||||
1 | L×W×H(mm) | 3345*1685*1605 | 3695*1685*1615 | 3695*1685*1615 | |
2 | Wheelbase(mm) | 2150 | 2500 | 2500 | |
3 | Minimum ground clearance(mm) | 130 | To be determined by R&D | 137 | |
4 | Curb weight(kg) | 1030 | To be determined by R&D | To be determined by R&D | |
5 | Passenger | 4 | 5 | 5 | |
6 | Rapid Recharge Function | ●support | ●support | ●support | |
7 | Rapid Recharge Power(kW) | 6.6 | 6.6 | 6.6 | |
8 | Rapid Recharge Time(h) | 0.5 | 0.5 | 0.5 | |
9 | Slower Recharge Time(h) | 4.7 | 7 | 7 | |
10 | Electric Quantity for Rapid Recharge(%) | 30-80 | 30-80 | 30-80 | |
■Motor/Battery/Electric Control Configuration | |||||
11 | Model of Electrical Machienry | PMSM | PMSM | PMSM | |
12 | Motor Power(kW) | 40 | 40 | 40 | |
13 | Max.Torque of Motor(N.m,Peak) | 110 | 110 | 100 | |
14 | Max.Speed(km/h) | 100 | 100 | 100 | |
15 | Type of Battery | PMSM | PMSM | PMSM | |
16 | Battery Capacity(kWh) | 28.08(CATL) | 28.08(CATL) | 43 | |
17 | Driving Mileage(km) CLTC | 300 | 300 | 400 | |
■Chassis | |||||
18 | Drive Mode | FF Layout | FF Layout | FF Layout | |
19 | Brake System(Front/Rear) | Disc/Drum | Disc/Disc | Disc/Disc | |
20 | Hub material | Steel | Steel | Steel | |
21 | Tyre Size | R15 | R15 | R15 | |
22 | Front Suspension Type | Mcphersonin | Mcphersonin | Mcphersonin | |
23 | Rear Suspension Type | Torsion Beam | Torsion Beam | Torsion Beam | |
■Safety | |||||
24 | ABS | ● | ● | ● | Regulatory requirement |
25 | EBD | ● | ● | ● | |
26 | Traction Control(ASR/TCS/TRC) | - | ● | ● | |
27 | Bodywork Stability Control(ESC/ESP/DCS) | - | ● | ● | |
28 | AutoHold | - | ● | ● | |
29 | Driver side airbag | ● | ● | ● | |
30 | Codriver side airbag | ● | ● | ● | |
31 | The driver's seat belt reminder | ● | ● | ● |
Driver and passenger are wearing seatbelt reminders |
32 | Door Not Closed remidner | ● | ● | ● | |
33 | 360°panoramic image | ● | ● | ● | |
34 | ISO-FIX child safety seat interface | ● | ● | ● | |
35 | Tire pressure monitor | ● | ● | ● | |
36 | Low speed pedestrian warning(AVAS) | ● | ● | ● | |
37 | Manual anti-glare rearview mirror | ● | ● | ● | |
38 | Front/Rear Parking Radar | Front -/Rear ● | Front -/Rear ● | Front -/Rear ● | |
■External | |||||
39 | LED Lamp | ● | ● | ● | |
40 | Follow me home | ● | ● | ● | |
41 | Daytime running light | ● | ● | ● | |
42 | Height electricly adjustmentable headlights | ● | ● | ● | |
43 | glass | white | white | white | |
■Interior System | |||||
44 | Instrument cluster | ● 6.7 Inch | ● 6.7 Inch | ● 6.7 Inch | |
45 | Shift mode | ●Manual | ●Manual | ●Manual | |
46 | Steering wheel Material | ●PU | ●PU | ●PU | |
47 | Multifunction steering wheel | ● | ● | ● | |
48 | Seats Material | ● Fabric | ● Fabric | ● Fabric | |
49 | Main driver seats direction adjustment | ● Manual 4 direction | ●Manual 6 Direction(Large angle or flat backrest) | ●Manual 6 Direction(Large angle or flat backrest) | |
50 | Codriver seat direction adjustment | ● Manual 4 direction | ● Manual 4 direction | ● Manual 4 direction | |
51 | Co driver seat one button folding courtesy | ● | - | - | |
52 | Rear seats lowering | ●proportionally | ●proportionally | ●proportionally | |
■Convenience | |||||
53 | Electronic Power Assist EPS | ● | ● | ● | |
54 | Power window | ● | ● | ● | |
55 | Hidden door handle (manual) | - | - | - | |
56 | Hidden door handle (electric) | ● | ● | ● | |
57 | Parking form | ● Handbrake | ● Electric Handbrake | ● Electric Handbrake | |
58 | Brake Energy Recovery | ● | ● | ● | |
59 | Remote key | 2 | 2 | 2 | |
60 | Keyless Entry | ● | ● | ● | |
61 | Keyless Start | ● | ● | ● | |
62 | Uphill assist | ● | ● | ● | |
63 | Driving Recorder Interface | ● | ● | ● | 12V USB port |
64 | Cosmetic Mirror(Driver&Codriver Sunvisor) | ● | ● | ● | |
65 | Electric A/C (Single Cooling A/C) | ● | ● | ● | |
66 | Electric A/C (Cooling&Heating A/C) | ○Manual | ○Automatic | ○Automatic | |
67 | Online Music | - | - | - | |
68 | Navigation(off line) | - | ○ | ○ | |
69 | Online Voice Control | - | - | - | |
■Video Entertainment | |||||
70 | Central-control LCD Screen | ● 10.25 Inch | ● 10.25 Inch | ● 10.25 Inch | |
71 | Central Dashboard and Language | English/Thai/Indonesian | English/Thai/Indonesian | English/Thai/Indonesian | |
72 | Bluetooth | ● | ● | ● | |
73 | WIFI | ● | ● | ● | |
74 | Carplay | ●EASYCON/Apple carplay/Android AUTO(Batch development) | ●EASYCON/Apple carplay/Android AUTO(Batch development) | ●EASYCON/Apple carplay/Android AUTO(Batch development) | Batch development |
75 | No. of Loudspeaker | ●4 | ●6 | ●6 | |
76 | No. of USB | ●1 USB+1 Type C | ●1 USB+1 Type C | ●1 USB+1 Type C | |
77 | Car portable charger | ● | ● | ● | European standard |
78 | 7kw Slow filling pile | ○ | ○ | ○ | |
79 | V2XReverse charging gun | - | ● | ● | |
■Colorful car paint | |||||
80 | Vehicle Color | Same as the main project | Same as the main project | Same as the main project | |
■Accessory | |||||
81 | Standard for All Models | ● | ● | ● | |
■Warranty Policy | |||||
82 | Vehicle Warranty | 3 years / 100,000 km | 3 years / 100,000 km | 3 years / 100,000 km | |
83 | Warranty for core components (battery, motor, electronic control) | 8years / 150,000 km | 8years / 150,000 km | 8years / 150,000 km |
|
Remarks:"●”-Standard, “○”-Option, “-”- No. |
